Description of Voltage Detection Sensor Module 0-25V DC
Quick Overview
The Voltage Detection Sensor Module 0-25V DC is specifically designed for monitoring and detecting DC voltage levels in a circuit. Ideal for battery monitoring, power management systems, and educational applications, this module offers real-time voltage measurement within a 0-25V DC range.
How It Works
The module incorporates a voltage divider circuit that scales down the input voltage to a level readable by microcontrollers. The scaled-down voltage is then sent to an analog pin of the connected microcontroller. The microcontroller can convert this analog signal to a digital value, which can be processed to represent the actual voltage level.
Technical Specification
- Input Voltage Range: 0-25V DC
- Output Voltage Range: 0-3.3V DC (scaled)
- Operating Voltage: 3.3V to 5V DC
- Sampling Rate: User-defined (depends on the connected microcontroller)
- Accuracy: ±1%
Key Features
- Wide Voltage Range: Capable of measuring 0-25V DC, making it suitable for various applications.
- High Accuracy: Offers an accuracy level of ±1%, ensuring reliable data acquisition.
- Low Power Consumption: Efficient design, perfect for battery-operated devices.
- Versatility: Can be used with both 3.3V and 5V microcontrollers.
Application
- Battery level monitoring in portable devices
- Solar power systems for tracking panel voltage output
- Educational kits for teaching electrical and electronics concepts
- Power management systems in automation and industrial setups
- Research and Development projects requiring accurate voltage measurement
Summary
A Voltage Detection Sensor Module (0-25V DC) monitors voltage levels in the 0-25V DC range. It generates a signal when voltage falls within this range, useful for tasks like battery level monitoring and low-voltage protection in electronic systems.
